Sandvik Coromant - M10x1.50 M Metric 6HX Form Thread Forming Tap - Solid Carbide, TiCN Finish, 102.02mm OAL, 24mm Thread Length, Right Hand Thread, Series CoroTap 400
Item #: 49624315
Brand: Sandvik Coromant
Model #: 6183242
Exact Tooling IR#: 04
Features and Benefits
Thread forming taps do not cut threads; rather, they form threads by displacing material. They generate threads without producing chips.
Titanium carbonitride (TiCN) is harder and more wear resistant than TiN. It is used on stainless steels, cast iron and aluminum alloys.
Solid carbide provides better rigidity than high speed steel. It is extremely heat resistant and used for high speed applications on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
| Product Specifications | |
|---|---|
| Thread Size (mm) | M10x1.50 |
| Class of Fit | 6HX |
| Chamfer | Form Tap |
| Finish/Coating | TiCN |
| Material | Solid Carbide |
| Overall Length (Decimal Inch) | 4.0165 |
| Overall Length (mm) | 102.02 |
| Thread Standard | M;Metric |
| Thread Length (Decimal Inch) | 0.9449 |
| Thread Length (mm) | 24.00 |
| Series/List | CoroTap 400 |
| Tapping Depth (Decimal Inch) | 1.5354 |
| Tapping Depth (mm) | 39 |
| Thread Direction | Right Hand |
| Shank Diameter (Decimal Inch) | 0.3937 |
| Shank Diameter (mm) | 10.00 |
| Material Application | Non-Ferrous Materials; High Temperature Alloys; Steel; Stainless Steel |
