Scientific Cutting Tools - 5/16-24" Port, 0.3" Spotface Diam, 1/8" Tube Outside Diam, Plain Pilot, Solid Carbide Porting Tool
Item #: 44064947
Brand: Scientific Cutting Tools
Model #: MS33514-2A
Features and Benefits
Solid carbide is extremely heat resistant and used for high speed applications on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
| Product Specifications | |
|---|---|
| Port Standard Designation | AS 33514; MS 33514 |
| Pilot Type | Plain |
| Port Thread Size (Decimal Inch) | 0.3120-24 |
| Port Thread Size (Inch) | 5/16-24 |
| Tool Material | Solid Carbide |
| Tube Dash Number | 2.000 |
| Tube Outside Diameter Compatibility (Decimal Inch) | 0.125 |
| Tube Outside Diameter Compatibility (Inch) | 1/8 |
| Minimum Pilot Diameter (Decimal Inch) | 0.0910 |
| Maximum Pilot Diameter (Decimal Inch) | 0.1370 |
| Spotface Diameter (Decimal Inch) | 0.3000 |
| Pilot Length (Decimal Inch) | 0.1920 |
| Identification Groove | No |
| Workpiece Compatibility | Tubes |
| Finish/Coating | AlTiN+ |
| Head Length (Decimal Inch) | 1.0000 |
| Overall Length (Decimal Inch) | 3.0000 |
| Shank Diameter (Decimal Inch) | 0.3750 |
| Shank Length (Decimal Inch) | 2.0000 |
| Seal Angle | 12 |
| Thread Type | UNJF |
| Flute Type | Straight |
| Number of Flutes | 3 |
