Sandvik Coromant - TRDC1312 M Grade 2025 Carbide Turning Insert - TiCN/Al2O3/TiN Finish, 55° Triangle, 13mm Inscr Circle, 12mm Thick, 3/64" Corner Radius
Item #: 49420599
Brand: Sandvik Coromant
Model #: 5755191
Exact Tooling IR#: 04
Features and Benefits
Solid carbide is extremely heat-resistant and used for high speed applications on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
| Product Specifications | |
|---|---|
| Insert Style | TRDC |
| Insert Size | 1312 |
| Material | Carbide |
| Length (mm) | 13.00 |
| Length (Decimal Inch) | 0.5118 |
| Inscribed Circle (mm) | 13.00 |
| Inscribed Circle (Decimal Inch) | 0.5118 |
| Thickness (Decimal Inch) | 0.4724 |
| Thickness (mm) | 12.00 |
| Corner Radius (Inch) | 3/64 |
| Corner Radius (mm) | 1.19 |
| Corner Radius (Decimal Inch) | 0.0469 |
| Manufacturer's Grade | 2025 |
| Coating | TiCN/Al2O3/TiN |
| Chip Breaker | M |
| Hole Diameter (mm) | 3.70 |
| Hole Diameter (Decimal Inch) | 0.1457 |
| ISO Number | TRDC1312M2025 |
| Relief Angle | 7 |
| Coating Process | MTCVD |
| Manufacturers Catalog Number | 5755191 |
| Primary Workpiece Material | M |
| Included Angle | 55 |
| Cutting Direction | Neutral |
| Insert Hand | Neutral |
| Series | CoroTurn TR |
| Maximum Depth of Cut (mm) | 11.80 |
| Maximum Depth of Cut (Decimal Inch) | 0.4646 |
| Insert Holding Method | Screw |
| Shape | Triangle |
