Sandvik Coromant - 3/8-16 UNC 2B Modified Bottoming Thread Forming Tap - High Speed Steel, TiN Finish, 100mm OAL, 20mm Thread Length, Right Hand Thread, Series CoroTap 400
Item #: 49384845
Brand: Sandvik Coromant
Model #: 6181752
Exact Tooling IR#: 04
Features and Benefits
Modified bottoming chamfers are similar to bottoming chamfers, but they are longer and have more teeth. They are used for threading to the bottom of blind holes and have 2 to 2-1/2 threads.
Titanium Nitride (TiN) is a multi-purpose coating which increases chip flow in softer materials. The heat and hardness resistance allows the tool to run at higher speeds than uncoated tools.
High Speed Steel (HSS) provides good wear resistance and can be used in general purpose applications for both ferrous and nonferrous materials.
| Product Specifications | |
|---|---|
| Thread Size (Inch) | 3/8-16 |
| Class of Fit | 2B |
| Chamfer | Modified Bottoming |
| Finish/Coating | TiN |
| Material | High Speed Steel |
| Overall Length (Decimal Inch) | 3.9370 |
| Overall Length (mm) | 100.00 |
| Thread Standard | UNC |
| Thread Length (Decimal Inch) | 0.7874 |
| Thread Length (mm) | 20.00 |
| Series/List | CoroTap 400 |
| Neck Length (Decimal Inch) | 0.5040 |
| Tapping Depth (Decimal Inch) | 1.2913 |
| Tapping Depth (mm) | 33 |
| Thread Direction | Right Hand |
| Shank Diameter (Decimal Inch) | 0.3811 |
| Shank Diameter (mm) | 9.68 |
| Material Application | High Temperature Alloys; Non-Ferrous Metals; Stainless Steel; Steel |
