Iscar - 08IL Internal Left Hand 24 UN Laydown Threading Insert - Grade IC228, TiCN/TiN Coated Carbide, 4.76mm Inscribed Circle
Item #: 46698148
Brand: Iscar
Model #: 5999946
Exact Tooling IR#: 04
Features and Benefits
Solid carbide provides better rigidity than high speed steel. It is extremely heat resistant and used for high speed applications on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
| Product Specifications | |
|---|---|
| Material | Carbide |
| Insert Style | 08IL |
| Insert Hand | Left Hand |
| Thread Type | Internal |
| Thread Standard | UN |
| Manufacturer's Grade | IC228 |
| Internal Threads Per Inch | 24 |
| Internal Pitch (mm) | 24.00 |
| Threads Per Inch | 24 |
| Pitch (mm) | 24.00 |
| Inscribed Circle (mm) | 4.76 |
| Inscribed Circle (Decimal Inch) | 0.1870 |
| Coating | TiCN/TiN |
| Coating Process | PVD |
| Corner Radius (mm) | 0.05 |
| Corner Radius (Decimal Inch) | 0.0020 |
