Iscar - T490 LNAR0804 P Grade IC07 Carbide Milling Insert - Uncoated, 7.5mm Thick, 0.4mm Corner Radius
Item #: 46674354
Brand: Iscar
Model #: 5666820
Exact Tooling IR#: 04
Features and Benefits
Solid carbide provides better rigidity than high speed steel. It is extremely heat resistant and used for high speed applications on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
| Product Specifications | |
|---|---|
| Insert Style | T490 LNAR |
| Insert Size | 0804 |
| Material | Carbide |
| Material Grade | Fine Grain |
| Manufacturer's Grade | IC07 |
| Coating | Uncoated |
| Width (mm) | 4.25 |
| Width (Decimal Inch) | 0.1670 |
| Length (mm) | 8.60 |
| Length (Decimal Inch) | 0.3390 |
| Thickness (mm) | 7.50 |
| Thickness (Decimal Inch) | 0.2950 |
| Corner Radius (Decimal Inch) | 0.0160 |
| Corner Radius (mm) | 0.40 |
| Shape | Tangential |
| Insert Hand | Right Hand |
| Chipbreaker | P |
| Maximum Depth of Cut (mm) | 8.00 |
| Maximum Depth of Cut (Decimal Inch) | 0.3150 |
| Cutting Edge Style | Helical |
| Manufacturers Catalog Number | T490 LNAR 0804PN-R-P |
| ISO Number | T490 LNAR 0804PN-R-P |
| ANSI Number | T490 LNAR 0804PN-R-P |
