Iscar - CCMT3-2 FPC Grade IC520N Carbide Turning Insert - TiCN/TiN Finish, 80° Diamond, 9.52mm Inscr Circle, 3.97mm Thick, 0.8mm Corner Radius
Item #: 46667598
Brand: Iscar
Model #: 6170092
Exact Tooling IR#: 04
Features and Benefits
Solid carbide is extremely heat-resistant and used for high speed applications on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
| Product Specifications | |
|---|---|
| Insert Style | CCMT |
| Insert Size | 3-2 |
| Material | Carbide |
| Length (mm) | 9.70 |
| Length (Decimal Inch) | 0.3820 |
| Inscribed Circle (mm) | 9.52 |
| Inscribed Circle (Decimal Inch) | 0.3750 |
| Thickness (Decimal Inch) | 0.1560 |
| Thickness (mm) | 3.97 |
| Corner Radius (mm) | 0.80 |
| Corner Radius (Decimal Inch) | 0.0310 |
| Manufacturer's Grade | IC520N |
| Coating | TiCN/TiN |
| Chip Breaker | FPC |
| ISO Number | CCMT 3-2-FPC |
| Relief Angle | 7 |
| Coating Process | PVD |
| Manufacturers Catalog Number | 6170092 |
| Primary Workpiece Material | M; P |
| Secondary Workpiece Material | None |
| Included Angle | 80 |
| Insert Hand | Right Hand |
| Maximum Depth of Cut (mm) | 2.80 |
| Maximum Depth of Cut (Decimal Inch) | 0.1100 |
| Multi Use Application | Turning |
| Shape | Diamond |
