Iscar - H490 ANKX1706 RM Grade IC810 Carbide Milling Insert - AlTiN/TiN Finish, 10.4mm Thick, 0.8mm Corner Radius
Item #: 46654778
Brand: Iscar
Model #: 3305115
Exact Tooling IR#: 04
Features and Benefits
Solid carbide provides better rigidity than high speed steel. It is extremely heat resistant and used for high speed applications on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
| Product Specifications | |
|---|---|
| Insert Style | H490 ANKX |
| Insert Size | 1706 |
| Material | Carbide |
| Manufacturer's Grade | IC810 |
| Coating | AlTiN/TiN |
| Width (mm) | 11.20 |
| Width (Decimal Inch) | 0.4410 |
| Length (mm) | 16.70 |
| Length (Decimal Inch) | 0.6570 |
| Thickness (mm) | 10.40 |
| Thickness (Decimal Inch) | 0.4090 |
| Corner Radius (Decimal Inch) | 0.0310 |
| Corner Radius (mm) | 0.80 |
| Coating Process | PVD |
| Shape | Rectangle |
| Insert Hand | Right Hand |
| Chipbreaker | RM |
| Cutting Edge Style | Helical |
| Manufacturers Catalog Number | H490 ANKX 1706PNTR-RM |
| ISO Number | H490 ANKX 1706PNTR-RM |
| ANSI Number | H490 ANKX 1706PNTR-RM |
