Brand: Seco / Part #: 10127496
Item #: 40068017
Brand: Seco
Model #: 10127496
Product Specifications
| Minimum Cutting Diameter (mm) | 50.00 |
| Maximum Cutting Diameter (mm) | 50.00 |
| Maximum Depth of Cut (mm) | 68.00 |
| Cutter Style | R217.81 |
| Shank Type | Combination |
| Shank Diameter (mm) | 32.0000 |
| Maximum Ramping Angle | 0 |
| Insert Holding Method | Screw |
| Overall Length (mm) | 150.0000 |
| Tool Material | Steel |
| Series | R217.81 |
| Flute Type | Helical |
| Lead Angle | 90 |
| Shank Length (mm) | 60.000 |
| Head Length (mm) | 79.00 |
| Maximum RPM | 8300.000 |
| Tool Application | Slotting; Shouldering |
| Tool Performance | General Purpose |
| Primary Workpiece Material | Universal |
| End Mill Type | Helical End Mill |
| Rake | Positive |
| Complete Insert Compatibility | SNGU1306; SNXU1306; ACET1506; ACMT1506 |
| Insert Compatibility | SNGU1306; SNXU1306; ACET1506; ACMT1506 |
| Hand of Holder | Right Hand |
| Multi-Use Tool | Yes |
| ISO Number | R217.81-3250.3S-068-SNAC15.2 |
| Number of Inserts Included in Order | 0 |
| Usable Length (mm) | 79.000 |
| Number Of Flutes | 2 |
| Number Of Cutter Inserts | 12 |
| Coolant Through | No |
