Tool-Flo - FLPGL51, AC3R Grade Carbide Profiling Insert - TiAlN Finish, 55° Incl Angle, Parallelogram, 1/8" Thick, 0.015" Corner Radius
Item #: 42867325
Brand: Tool-Flo
Model #: 641G51AC3R
Exact Tooling IR#: 04
Features and Benefits
Solid carbide is extremely heat resistant and used for high speed applications on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
| Product Specifications | |
|---|---|
| Material | Carbide |
| Insert Style | FLPGL |
| Insert Size | 51 |
| Manufacturer's Grade | AC3R |
| Width (Decimal Inch) | 0.2500 |
| Thickness (Decimal Inch) | 0.1250 |
| Corner Radius (Decimal Inch) | 0.0150 |
| Relief Angle | 8 |
| Coating | TiAlN |
| Length (Decimal Inch) | 0.3750 |
| Rake | Positive |
| Rake Angle | 10 |
| Coating Process | PVD |
| Included Angle | 55 |
| Cutting Direction | Left Hand |
| Insert Hand | Left Hand |
| Insert Holding Method | Clamp |
| Shape | Parallelogram |
