Brand: Widia / Part #: 2003601
Item #: 99761843
Brand: Widia
Model #: 2003601
Product Specifications
| Connection Type | Shell Mount |
| Cutting Width (mm) | 14.00 |
| Maximum Depth of Cut (mm) | 12.00 |
| Hole Diameter (Inch) | 1-1/16 |
| Hole Diameter (Mm) ( - 0 Decimals) | 27.0000 |
| Cutter Diameter (mm) | 100.00 |
| Cutting Direction | Neutral |
| Insert Holding Method | Screw |
| Number Of Cutter Inserts | 6 |
| Compatible Insert Style | MDHX |
| Compatible Insert Size Code | 09T3.. |
| Staggered Tooth | No |
| Tooth Type | Straight |
| Rake | Positive |
| Tool Material | Steel |
| Series | M900 |
| Toolholder Style | M900 |
| Hub Diameter (mm) | 48.000 |
| Maximum RPM | 7070.000 |
| Tool Application | Slotting; Back Facing |
| Tool Performance | General Purpose |
| Primary Workpiece Material | Universal |
| Minimum Cutting Width (Decimal Inch) | 0.4724 |
| Maximum Cutting Width (mm) | 14.00 |
| Minimum Cutting Diameter (mm) | 100.00 |
| Lead Angle | 90 |
| Maximum Body Diameter (mm) | 98.56 |
| Weldon Flat | No |
| Manufacturers Catalog Number | 12399110200 |
| Insert Inscribed Circle (Decimal Inch) | 0.3750 |
| Overall Length (mm) | 33.0000 |
| Insert Inscribed Circle (Inch) | 3/8 |
| Number Of Teeth | 6 |
| Coolant Through | No |
| Complete Insert Compatibility | MD__09T3__ |
| Coating/Finish | Coated |
| Overall Height (Mm - 5 Decimals) | 33.00000 |
