Seco - 5/8-11 UNC 2BX H6 Thread Limit Modified Bottoming Thread Forming Tap - Vanadium High Speed Steel, TiN Finish, 110mm OAL, 25mm Thread Length, Right Hand Thread
Item #: 42627455
Brand: Seco
Model #: 52611
Exact Tooling IR#: 04
Features and Benefits
Modified bottoming chamfers are similar to bottoming chamfers, but they are longer and have more teeth. They are used for threading to the bottom of blind holes and have 2 to 2-1/2 threads.
Titanium Nitride (TiN) is a multi-purpose coating which increases chip flow in softer materials. The heat and hardness resistance allows the tool to run at higher speeds than uncoated tools.
Vanadium High Speed Steel (HSSE) is made of high speed steel, carbon, vanadium carbide and other alloys to increase abrasive wear resistance and toughness. It is commonly used in general applications on stainless steels and high silicon aluminums.
| Product Specifications | |
|---|---|
| Thread Size (Inch) | 5/8-11 |
| Class of Fit | 2BX |
| Thread Limit | H6 |
| Chamfer | Modified Bottoming |
| Finish/Coating | TiN |
| Material | Vanadium High Speed Steel |
| Overall Length (Decimal Inch) | 4.3307 |
| Overall Length (mm) | 110.00 |
| Thread Standard | UNC |
| Thread Length (Decimal Inch) | 0.9843 |
| Thread Length (mm) | 25.00 |
| Neck Length (Decimal Inch) | 1.6929 |
| Neck Length (mm) | 43 |
| Tapping Depth (Decimal Inch) | 2.6772 |
| Tapping Depth (mm) | 68 |
| Thread Direction | Right Hand |
| Shank Diameter (Decimal Inch) | 0.4724 |
| Shank Diameter (mm) | 12.00 |
| Shank Length (Decimal Inch) | 1.65 |
| Shank Length (mm) | 42 |
| Square Length (mm) | 9 |
