Kennametal - RCMK35, KCP25B Grade Carbide Profiling Insert - TiOCN Finish, 8° Relief Angle, Round, 13.23mm Thick, 1/2" Inscribed Circle
Item #: 42423913
Brand: Kennametal
Model #: 5940803
Exact Tooling IR#: 04
Features and Benefits
Solid carbide is extremely heat resistant and used for high speed applications on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
| Product Specifications | |
|---|---|
| Material | Carbide |
| Insert Style | RCMK |
| Insert Size | 35 |
| Manufacturer's Grade | KCP25B |
| Inscribed Circle (Inch) | 1/2 |
| Inscribed Circle (Decimal Inch) | 0.5000 |
| Thickness (mm) | 13.23 |
| Insert Height (mm) | 13.23 |
| Corner Radius (mm) | 0.00 |
| Relief Angle | 8 |
| Coating | TiOCN |
| Coating Process | CVD |
| Secondary Workpiece Material | K |
| Primary Workpiece Material | P |
| Cutting Direction | Neutral |
| Insert Hand | Neutral |
| Shape | Round |
