Kyocera - CNMM43 SX Grade PR005S Carbide Turning Insert - Megacoat Hard Finish, 80° Diamond, 1/2" Inscr Circle, 3/16" Thick, 0" Corner Radius
Item #: 41605056
Brand: Kyocera
Model #: 8858282
Exact Tooling IR#: 04
Features and Benefits
Solid carbide is extremely heat-resistant and used for high speed applications on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
| Product Specifications | |
|---|---|
| Insert Style | CNMM |
| Insert Size | 43 |
| Material | Carbide |
| Inscribed Circle (Decimal Inch) | 0.5000 |
| Inscribed Circle (Inch) | 1/2 |
| Thickness (Inch) | 3/16 |
| Thickness (Decimal Inch) | 0.1875 |
| Corner Radius (Inch) | 0 |
| Manufacturer's Grade | PR005S |
| Coating | Megacoat Hard |
| Chip Breaker | SX |
| ISO Number | CNMM1204XR-SXPR005S |
| Rake | Negative |
| Relief Angle | 0 |
| Coating Process | PVD |
| Primary Workpiece Material | S |
| Included Angle | 80 |
| Insert Hand | Right Hand |
| Insert Holding Method | Clamp |
| Shape | Diamond |
