OSG - TNKU120608 GR Grade XC1015 Carbide Milling Insert - Al2O3/TiCN Finish, 6.55mm Thick, 10.8mm Inscribed Circle, 0.8mm Corner Radius
Item #: 39403779
Brand: OSG
Model #: 7812090
Exact Tooling IR#: 04
Features and Benefits
Solid carbide provides better rigidity than high speed steel. It is extremely heat resistant and used for high speed applications on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
| Product Specifications | |
|---|---|
| Insert Style | TNKU |
| Insert Size | 120608 |
| Material | Carbide |
| Manufacturer's Grade | XC1015 |
| Coating | Al2O3/TiCN |
| Width (mm) | 10.80 |
| Length (mm) | 10.80 |
| Inscribed Circle (mm) | 10.80 |
| Thickness (mm) | 6.55 |
| Corner Radius (mm) | 0.80 |
| Coating Process | CVD |
| Shape | Triangle |
| Insert Hand | Right Hand |
| Chipbreaker | GR |
