Seco - LNMX301940 R2 Grade TP0501 Carbide Turning Insert - Al2O3 Finish, 90° Rectangle, 12mm Inscr Circle, 3/4" Thick, 5/32" Corner Radius
Item #: 37202025
Brand: Seco
Model #: 18855
Exact Tooling IR#: 04
Features and Benefits
Solid carbide is extremely heat-resistant and used for high speed applications on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
| Product Specifications | |
|---|---|
| Insert Style | LNMX |
| Insert Size | 301940 |
| Material | Carbide |
| Inscribed Circle (mm) | 12.00 |
| Inscribed Circle (Decimal Inch) | 0.4724 |
| Thickness (Inch) | 3/4 |
| Thickness (Decimal Inch) | 0.7500 |
| Corner Radius (Inch) | 5/32 |
| Corner Radius (mm) | 4.00 |
| Corner Radius (Decimal Inch) | 0.1575 |
| Manufacturer's Grade | TP0501 |
| Coating | Al2O3 |
| Chip Breaker | R2 |
| Hole Diameter (mm) | 6.35 |
| Hole Diameter (Decimal Inch) | 0.2500 |
| Rake | Negative |
| Relief Angle | 0 |
| Coating Process | Duratomic |
| Primary Workpiece Material | P |
| Secondary Workpiece Material | K |
| Included Angle | 90 |
| Cutting Direction | Neutral |
| Insert Hand | Neutral |
| Insert Holding Method | Lever Lock |
| FullRadius | No |
| Shape | Rectangle |
