Walter-Prototyp - M24x3.00 Metric 6H 4 Flute TiN Finish Cobalt Straight Flute Machine Tap - Modified Bottoming, Right Hand Thread, 200mm OAL, 36mm Thread Length, Oversize, Through Coolant
Item #: 36369866
Brand: Walter-Prototyp
Model #: 5076366
Exact Tooling IR#: 04
Features and Benefits
Modified bottoming is similar to bottoming, but the chamfer is longer and has more teeth. They are used for threading blind holes and have 2 to 2-1/2 threads.
Cobalt is harder than high speed steel and provides better wear resistance. It is commonly used on high tensile alloys.
Titanium Nitride (TiN) is a multi-purpose coating which increases chip flow in softer materials. The heat and hardness resistance allows the tool to run at higher speeds than uncoated tools.
| Product Specifications | |
|---|---|
| Tap Type | Machine Tap |
| Thread Size (mm) | M24x3.00 |
| Class of Fit | 6H |
| Number of Flutes | 4 |
| Chamfer | Modified Bottoming |
| Material | Cobalt |
| Finish/Coating | TiN |
| Thread Direction | Right Hand |
| Through Coolant | Through Coolant |
| Thread Standard | Metric |
| Overall Length (Decimal Inch) | 7.87400 |
| Overall Length (mm) | 200.00 |
| Oversize | No |
| Material Grade | M35 |
| Series/List | 2036155 |
| Thread Length (Decimal Inch) | 1.4173 |
| Thread Length (mm) | 36.00 |
| Neck Length (mm) | 84.00 |
| Neck Length (Decimal Inch) | 3.3071 |
| Tapping Depth (mm) | 120 |
| Shank Diameter (Decimal Inch) | 0.7087 |
| Shank Diameter (mm) | 18.00 |
| Square Size (Decimal Inch) | 0.5709 |
| Square Size (mm) | 14.50 |
| Material Application | Aluminum; Cast Steel; Fiber Reinforced Plastics; Graphite; Grey Cast Iron; Malleable Cast Iron; Non-Ferrous Metals; Plastics; Spheroidal Cast Iron; Steel; Vermicular Cast Iron |
