Value Collection - 1/8" Bore Diam, 5/16" OD, Open Miniature Radial Ball Bearing - 7/64" Wide, 1 Row, Round Bore, 40 Lb Static Capacity, 124 Lb Dynamic Capacity
Item #: 35381177
Brand: Value Collection
Exact Tooling IR#: 04
Features and Benefits
Minature radial ball bearings are ideal for spall apces and low friction applications. They are used in areas where there is low opperating torque and with bore and outside diamater tolerance ranges of +0.0000" to -0.0002".
Open Bearing design without seals or shields and are intended to be lubricated in place and periodically maintained
Round bore bearings are designed for mounting on round shafts.
| Product Specifications | |
|---|---|
| Type | Miniature |
| Style | Open |
| Bore Diameter (Decimal Inch) | 0.1250 |
| Outside Diameter (Decimal Inch) | 0.3125 |
| Width (Decimal Inch) | 0.1094 |
| Flange Type | Without Flange |
| Number of Rows | 1 |
| Bore Type | Round |
| Housing Material | Stainless Steel |
| Snap Ring Included | Without Snap Ring |
| Static Load Capacity (Lb.) | 40 |
| Dynamic Load Capacity (Lb.) | 124 |
| ABEC Scale | ABEC-5 |
| Inner Ring Width (Inch) | 0.1406 |
| Bearing Number | SRW2-5 |
