Brand: Ingersoll-Rand / Part #: 71459150
Item #: 99823437
Brand: Ingersoll-Rand
Model #: 71459150
Product Specifications
| Winch Type | Lifting & Pulling |
| Load Rating 1st Layer | 16800 lb |
| Load Rating Mid-drum | 13900 lb |
| Load Rating Full Drum | 11000 lb |
| Number Of Speeds | Variable |
| Winch Gear Type | Planetary |
| Line Speed Full Drum | 16 ft/min |
| Air Consumption | 700.00 |
| Required Pressure | 90 psi |
| Hose Size | 1.25 in |
| Brake Included | Yes |
| Body Material | Steel |
| Cable Diameter | 0.75 in |
| Cable Length | 1346.000 |
| Pulling Direction | Omnidirectional |
| Number Of Mounting Holes | 8.000 |
| Color | Yellow |
| Motor Type | Piston Motor |
| Portable | No |
| Overall Height | 36.5 in |
| Overall Length | 60.50 |
| Overall Width | 35 |
| Standards | ANSI.ASME B30.7, CE and FEM Classification 1 Bm or M5 (for -CE models), or other 3rd party type approvals |
| Series | FA5i-24XK1 Infinity Air Winch |
