Seco - RNMU1204M0 ME10 Grade MP2050 Carbide Milling Insert - TiAlN/TiSiN Finish, 3/16" Thick, 12mm Inscribed Circle, 6mm Corner Radius
Item #: 33672890
Brand: Seco
Model #: 46913
Exact Tooling IR#: 04
Features and Benefits
Solid carbide provides better rigidity than high speed steel. It is extremely heat resistant and used for high speed applications on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
| Product Specifications | |
|---|---|
| Insert Style | RNMU |
| Insert Size | 1204M0 |
| Material | Carbide |
| Material Grade | C3/C4 |
| Manufacturer's Grade | MP2050 |
| Coating | TiAlN/TiSiN |
| Width (mm) | 12.00 |
| Length (mm) | 12.00 |
| Inscribed Circle (mm) | 12.00 |
| Thickness (Inch) | 3/16 |
| Thickness (Decimal Inch) | 0.1875 |
| Corner Radius (mm) | 6.00 |
| Rake Angle | 27 |
| Rake | Negative |
| Coating Process | PVD |
| Included Angle | 0 |
| Shape | Round |
| Insert Hand | Neutral |
| Chipbreaker | ME10 |
| Maximum Depth of Cut (mm) | 6.00 |
| Maximum Depth of Cut (Decimal Inch) | 0.2362 |
| Cutting Edge Style | Chamfered & Honed |
| ISO Number | RNMU1204M0-ME10 |
