PRO-SOURCE - 1/4", 3/2 Way Single Stacking Solenoid Valve - 24 VDC, 0.98 CV Rate, 2.6" High x 5.12" Long
Item #: 31880305
Brand: PRO-SOURCE
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | 3/2 Way Single Solenoid |
| Actuator Type | Internal Pilot |
| Number of Positions | 2 |
| Number of Positions | 2 Position Normally Closed |
| Valve Type | 3-Way |
| Return Type | Spring |
| Voltage | 24 VDC |
| CV Rating | 0.980 |
| Inlet Size (Inch) | 1/4 |
| Outlet Size (Inch) | 1/4 |
| Cubic Feet per Minute | 50.91 |
| Length (Decimal Inch) | 5.120 |
| Height (Inch) | 2.6 |
| Maximum Temperature (F) | 122 |
| Maximum Working Pressure (psi) | 113 |
| For Use With | Compressed Air |
