Kennametal - SPHX070304 R21 Grade KCU25 Carbide Indexable Drill Insert - TiN Finish, Square, 5/16" Inscribed Circle
Item #: 31548688
Brand: Kennametal
Model #: 5692810
Exact Tooling IR#: 04
Features and Benefits
Solid carbide is extremely heat resistant and used for high speed applications. It is commonly used on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
Titanium nitride (TiN) is a multi-purpose coating which increases chip flow in softer materials. The heat and hardness-resistance allows the tool to run at higher speeds than uncoated tools.
| Product Specifications | |
|---|---|
| Insert Style | SPHX |
| Insert Size | 070304 |
| Material | Carbide |
| Manufacturer's Grade | KCU25 |
| Inscribed Circle (Inch) | 5/16 |
| Thickness (Inch) | 1/8 |
| Corner Radius (Inch) | 1/64 |
| Shape | Square |
| Length (Decimal Inch) | 0.3125 |
| Hole Diameter (mm) | 2.85 |
| Included Angle | 90 |
| Coating | TiN |
| Coating Process | PVD |
| Cutting Direction | Right Hand |
| Chipbreaker | R21 |
