Barksdale - 450 to 7,500 psi Adjustable Range, 15,000 Max psi, Sealed Piston Pressure Switch - 1/4 NPT Female, Screw Terminals, SPDT Contact, 316SS Wetted Parts, 2% Repeatability
Item #: 31040983
Brand: Barksdale
Model #: 9617-6SS
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Maximum Adjustable Range | 7500 psi |
| Minimum Adjustable Range | 450 psi |
| Type | Sealed Piston Pressure Switch |
| Maximum Pressure Setting | 15000 psi |
| Thread Size | 1/4 |
| Thread Type | NPT Female |
| Electrical Connection | Screw Terminals |
| Amperage Rating | 10 Amp@125/250/480VAC; 0.03 Amp@250VDC |
| Repeatability | 2% |
| Contact Form | SPDT |
| Maximum Adjustable Range on Fall | 7500 |
| Maximum Adjustable Range on Rise | 7500 |
| Maximum Deadband | 400.00 |
| Maximum Setpoint Deadband | 400.00 |
| Maximum Temperature (C) | 74 |
| Maximum Temperature (F) | 165 |
| Minimum Adjustable Range on Fall | 450 |
| Minimum Adjustable Range on Rise | 450 |
| Minimum Deadband | 125 psi |
| Minimum Setpoint Deadband | 125.00 |
| Minimum Temperature (C) | -29 |
| Minimum Temperature (F) | -20 |
| Additional Information | 316SS |
