Barksdale - 43 to 650 psi Adjustable Range, 1,200 Max psi, Compact Pressure Switch - G 1/4 Female, M12 Plug, SPDT Contact, 300SS Wetted Parts, 2% Repeatability
Item #: 31039589
Brand: Barksdale
Model #: 82C1MV
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Maximum Adjustable Range | 650 psi |
| Minimum Adjustable Range | 43 psi |
| Type | Compact Pressure Switch |
| Maximum Pressure Setting | 1200 psi |
| Thread Size | G 1/4 |
| Thread Type | Female |
| Electrical Connection | M12 Plug |
| Amperage Rating | 3 Amp@250VAC; 5 Amp@125VAC; 3 Amp@30VDC |
| Repeatability | 2% |
| Contact Form | SPDT |
| Maximum Adjustable Range on Fall | 650 |
| Maximum Adjustable Range on Rise | 650 |
| Maximum Deadband | 97.50 |
| Maximum Setpoint Deadband | 97.50 |
| Maximum Temperature (C) | 75 |
| Maximum Temperature (F) | 167 |
| Minimum Adjustable Range on Fall | 43 |
| Minimum Adjustable Range on Rise | 43 |
| Minimum Deadband | 0 psi |
| Minimum Setpoint Deadband | 0.00 |
| Minimum Temperature (C) | -20 |
| Minimum Temperature (F) | -4 |
| Additional Information | 300SS; FKM Seal |
