Sandvik Coromant - Modular Turning & Profiling Cutting Unit Heads; System Size: C3 ; Series Name: T-Max P ; Cutting Direction: Right Hand ; Head Length/Projection (mm): 40.00 ; Insert Style: CNMG ; Internal or External: External
Item #: 20181814
Brand: Sandvik Coromant
Model #: 7951262
Product Specifications
Modular Turning & Profiling Cutting Unit Heads; System Size: C3 ; Series Name: T-Max P ; Cutting Direction: Right Hand ; Head Length/Projection (mm): 40.00 ; Insert Style: CNMG ; Internal or External: External
| System Size | C3 |
| Series Name | T-Max P |
| Cutting Direction | Right Hand |
| Head Length/Projection (mm) | 40.00 |
| Insert Style | CNMG |
| Internal or External | External |
| Center to Cutting Edge (mm) | 27.00 |
| Insert Holding Method | Screw/Clamp |
| Through Coolant | Through Coolant |
| Maximum Hole Depth (mm) | 109.00 |
| Minimum Hole Diameter (mm) | 109.00 |
| Axial Rake Angle | -6 |
| Radial Rake Angle | -6 |
| Neck Diameter (mm) | 32.000 |
| Center to Cutting Height (mm) | 40.00 |
| Complete Insert Compatibility | CNMG 120408 |
| Head Connection Size | 32 |
