Air Cylinders; Type: Double Acting; Bore Size (Decimal Inch): 2-1/2; Rod Diameter (Decimal Inch): 0.6250; Stroke Length (Decimal Inch): 1.0000; Mounting Style: Flush Bottom; Port Size: 1/4; Port Type: NPT; Width (Decimal Inch): 3.0000; Length (Decimal Inc
Item #: 17775628
Brand: Mead
Model #: FM-MS4-2.5X1
Product Specifications
| Type | Double Acting |
| Bore Size (Decimal Inch) | 2-1/2 |
| Rod Diameter (Decimal Inch) | 0.6250 |
| Stroke Length (Decimal Inch) | 1.0000 |
| Mounting Style | Flush Bottom |
| Port Size | 1/4 |
| Port Type | NPT |
| Width (Decimal Inch) | 3.0000 |
| Length (Decimal Inch) | 6.5000 |
| Mount Thread | 3/8-16 |
| Seal Material | Nitrile/Carbon |
| Maximum Working Pressure (psi) | 250.000 |
| Rod Thread Size | 7/16-20 |
| Cushions | None |
