Insize USA LLC - DRO Linear Scales; Scale Type: Linear Scale ; Maximum Measuring Range (mm): 200.00 ; Maximum Measuring Range (Decimal Inch): 8.0000 ; Resolution (Micron): 5.00 ; Resolution (mm): 0.005 (5 ?m Scales) ; Resolution (Decimal Inch): 0.0002
Item #: 15521016
Brand: Insize USA LLC
Model #: ISL-A5-200
Product Specifications
DRO Linear Scales; Scale Type: Linear Scale ; Maximum Measuring Range (mm): 200.00 ; Maximum Measuring Range (Decimal Inch): 8.0000 ; Resolution (Micron): 5.00 ; Resolution (mm): 0.005 (5 ?m Scales) ; Resolution (Decimal Inch): 0.0002
| Scale Type | Linear Scale |
| Maximum Measuring Range (mm) | 200.00 |
| Maximum Measuring Range (Decimal Inch) | 8.0000 |
| Resolution (Micron) | 5.00 |
| Resolution (mm) | 0.005 (5 ?m Scales) |
| Resolution (Decimal Inch) | 0.0002 |
| Scale Length (mm) | 349.00 |
| Accuracy (micrometer) | ??5+5L/1000) |
| Accuracy (Decimal Inch) | 0.0200 |
| Series | ISL-A5 |
| IP Rating | IP54 |
| Cable Connection Type | RS232 |
| Cable Length (Decimal Inch) | 140.0000 |
| Cable Length (Meters) | 3.50 |
| Operating Temperature Range (C) | 0 to 40 |
