Hayward - Check Valves; Design: In-line; True Union Ball Check ; Tube Outside Diameter (mm): 19.050 ; Pipe Size (Inch): 3/4 ; Tube Outside Diameter (Inch): 3/4 ; End Connections: Threaded ; Material: Polypropylene
Item #: 15516602
Brand: Hayward
Model #: TC30075T
Product Specifications
Check Valves; Design: In-line; True Union Ball Check ; Tube Outside Diameter (mm): 19.050 ; Pipe Size (Inch): 3/4 ; Tube Outside Diameter (Inch): 3/4 ; End Connections: Threaded ; Material: Polypropylene
| Design | In-line; True Union Ball Check |
| Tube Outside Diameter (mm) | 19.050 |
| Pipe Size (Inch) | 3/4 |
| Tube Outside Diameter (Inch) | 3/4 |
| End Connections | Threaded |
| Material | Polypropylene |
| Seal Material | FPM |
| Material Grade | ASTM D4101 |
| Crack Pressure (psi) | 3 |
| Maximum Temperature (F) | 250.000 |
| Minimum Temperature (F) | 40.000 |
| Overall Length (Decimal Inch) | 4.75000 |
| Maximum Working Pressure (psi) | 235.000 |
