Brand: Seco / Part #: 10127487
Item #: 79955217
Brand: Seco
Model #: 10127487
Product Specifications
| Minimum Cutting Diameter (Inch) | 2-1/2 |
| Maximum Cutting Diameter (Inch) | 2-1/2 |
| Maximum Depth of Cut (mm) | 69.00 |
| Arbor Hole Diameter (Inch) | 1 |
| Compatible Insert Size Code | SN.U1306; XO.X1605 |
| Maximum Ramping Angle | 1.5 |
| Cutter Style | R220.82 |
| Cutting Direction | Right Hand |
| Insert Holding Method | Screw |
| Lead Angle | 90 |
| Rake | Negative |
| Rake Angle | -13.000 |
| Series | R220.82 |
| Overall Height (Inch) | 3-1/2 |
| Keyway Width (mm) | 9.70 |
| Hub Diameter (mm) | 59.000 |
| Pitch Type | Close |
| Maximum RPM | 10500.000 |
| Tool Application | Shouldering |
| Tool Performance | General Purpose |
| Primary Workpiece Material | Universal |
| Keyway Depth (mm) | 5.70 |
| Number of Adjustable Pockets | 0 |
| ISO Number | R220.82-02.50-2.75-SNXO16.5A |
| Complete Insert Compatibility | SN.U1306; XO.X1605 |
| Toolholder Material | Steel |
| Manufacturers Catalog Number | R220.82-02.50-2.75-SNXO16.5A |
| Coolant Through | Yes |
| Number Of Cutter Inserts | 30 |
| Number Of Flutes | 5 |
