Circular Ring Terminal: Partially Insulated, 12 to 10 AWG, Crimp Connection #10 Stud, 1.024″ Long, 0.374″ Wide, Copper Contact, Yellow
Item #: 14737068
Brand: Value Collection
Model #: RNYD5-5
Product Specifications
| Terminal Type | Circular |
| Insulation Type | Partially Insulated |
| Connection Type | Crimp |
| Compatible Wire Size (AWG) | 12 to 10 |
| Compatible Wire Size (sq mm) | 4.00 to 6.00 |
| Insulation Material | Nylon |
| Color | Yellow |
| Stud Size (mm) | 5.30 |
| Stud Size (Letter) | M5 |
| Stud Size (#) | 10 |
| Contact Material | Copper |
| Contact Plating | TiN |
| Thickness (mm) | 1.00 |
| Thickness (Decimal Inch - 4 Decimals) | 0.0390 |
| Ring Width (mm) | 9.50 |
| Ring Width (Decimal Inch) | 0.3740 |
| Overall Length (mm) | 26.00 |
| Overall Length (Decimal Inch) | 1.0240 |
