Chamfer Mill: 1″ Dia, 4 Flutes, Solid Carbide 3″ OAL, 1″ Shank Dia, AlTiN Coated
Item #: 14565212
Brand: GWS
Model #: 108954
Product Specifications
| Cutter Head Diameter (Fractional Inch) | 1 in |
| Cutter Head Diameter (Decimal Inch) | 1.0000 |
| Length of Cut (Inch) | 1 |
| Shank Diameter (Decimal Inch) | 1.0000 |
| Shank Diameter (Inch) | 1 |
| Overall Length (Inch) | 3 |
| Overall Length (Decimal Inch) | 3.0000 |
| Tool Application | Chamfering; Profiling |
| Cutting Direction | Right Hand |
| Series | 244 |
| Tapered | No |
| Cutting Edge Style | Chamfered |
| Drill Point Angle | 90 |
| Included Angle A | 90.00 |
| Chamfer Mill Material | Solid Carbide |
| Number Of Flutes | 4 |
| Material Application | Non-Ferrous Metal; Super Alloys; Stainless Steel; Cast Iron; Steel |
| Length Of Cut (Decimal Inch - 4 Decimals) | 1.0000 |
| Coating/Finish | AlTiN |
| Single Or Double End | Single |
| Additional Information | Helix Angle: 30 deg; Alternate Part Number: CMS41000X; Endwork: Point |
