Corner Radius End Mill: 3/4″ Dia, 1-5/8″ LOC, 0.03″ Radius, 5 Flutes, Solid Carbide 6″ OAL, 3/4″ Shank Dia, 37 ° Helix, AlCromax Coated, Corner Radius End, Centercutting, Series 265
Item #: 14561005
Brand: GWS
Model #: 316997
Product Specifications
| Mill Diameter (Decimal Inch) | 0.7500 |
| Mill Diameter (Inch) | 3/4 |
| Length of Cut (Inch) | 1-5/8 |
| Corner Radius (Decimal Inch) | 0.0300 |
| Number Of Flutes | 5 |
| End Mill Material | Solid Carbide |
| Extended Reach | No |
| End Type | Corner Radius |
| Flute Type | Upcut |
| Helix Angle | 37 |
| Centercutting | Yes |
| Variable Index | Yes |
| Variable Helix | Yes |
| Shank Diameter (Inch) | 3/4 |
| Overall Length (Inch) | 6 |
| Overall Length (Decimal Inch) | 6.0000 |
| Cutting Direction | Right Hand |
| Flute Direction | Right Hand |
| Single Or Double End | Single |
| Manufacturers Catalog Number | 537L75026030C15 |
| Coating/Finish | AlCromax |
