Turning Insert: DNMG150408-MW5 WPP10G, Solid Carbide TiCN, Al2O3 & TiN Finish, Neutral, 0.6100″ Long, 1/2″ Inscribed Circle, 0.0310″ Corner Radius, N/A Diamond, Series DNMG
Item #: 11601838
Brand: Walter
Model #: 8115826
Product Specifications
| Insert Style | DNMG |
| Insert Shape Code | D |
| Insert Size Code | 150408 |
| Insert Shape | Diamond |
| Clearance Code | N |
| Tolerance Code | M |
| Insert Material | Solid Carbide |
| Manufacturer Grade | WPP10G |
| Hole Diameter (Decimal Inch) | 0.2030 |
| Maximum Depth of Cut (Decimal Inch) | 0.6100 |
| Inscribed Circle (Inch) | 1/2 |
| Inscribed Circle (Decimal Inch) | 0.5000 |
| Insert Holding Method | Pin; Clamp |
| Insert Hand | Neutral |
| Insert Thickness (Decimal Inch) | 0.1880 |
| Corner Radius (Decimal Inch) | 0.0310 |
| Relief Angle | 55 |
| Series | DNMG |
| Coating Process | CVD |
| Length Range (Decimal Inch) | 0.6000 - 0.6500 |
| Insert Length (Decimal Inch) | 0.6100 |
| Chip Breaker | MW5 |
| Coating/Finish | TiCN; TiN; Al2O3 |
