Kennametal - RCMK23, KC5010 Grade Carbide Profiling Insert - TiAlN Finish, 7° Relief Angle, Round, 9.09mm Thick, 1/4" Inscribed Circle
Item #: 09652678
Brand: Kennametal
Model #: 1865871
Exact Tooling IR#: 04
Features and Benefits
Solid carbide is extremely heat resistant and used for high speed applications on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
| Product Specifications | |
|---|---|
| Material | Carbide |
| Insert Style | RCMK |
| Insert Size | 23 |
| Material Grade | C3/C4 |
| Manufacturer's Grade | KC5010 |
| Inscribed Circle (Inch) | 1/4 |
| Inscribed Circle (Decimal Inch) | 0.2500 |
| Thickness (mm) | 9.09 |
| Thickness (Decimal Inch) | 0.3580 |
| Insert Height (mm) | 9.09 |
| Insert Height (Decimal Inch) | 0.3579 |
| Relief Angle | 7 |
| Coating | TiAlN |
| Length (Decimal Inch) | 0.3579 |
| Length (mm) | 9.09 |
| Rake | Positive |
| Coating Process | PVD |
| Series | K-Lock |
| Insert Holding Method | Clamp |
| Shape | Round |
