Kennametal - RCMK152, K313 Grade Carbide Profiling Insert - Uncoated, 7° Relief Angle, Round, 5/16" Thick, 3/16" Inscribed Circle
Item #: 09652538
Brand: Kennametal
Model #: 1163535
Exact Tooling IR#: 04
Features and Benefits
Solid carbide is extremely heat resistant and used for high speed applications on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
| Product Specifications | |
|---|---|
| Material | Carbide |
| Insert Style | RCMK |
| Insert Size | 152 |
| Material Grade | C3/C4 |
| Manufacturer's Grade | K313 |
| Inscribed Circle (Inch) | 3/16 |
| Inscribed Circle (Decimal Inch) | 0.1875 |
| Thickness (mm) | 6.38 |
| Thickness (Decimal Inch) | 0.2510 |
| Thickness (Inch) | 5/16 |
| Insert Height (mm) | 6.38 |
| Insert Height (Decimal Inch) | 0.2512 |
| Relief Angle | 7 |
| Coating | Uncoated |
| Length (Decimal Inch) | 0.2512 |
| Length (mm) | 6.38 |
| Rake | Positive |
| Series | K-Lock |
| Insert Holding Method | Clamp |
| Shape | Round |
