Heinrich - 12-3/4" Jaw Opening Capacity x 3" Throat Depth, Horizontal Drill Press Vise - 5-21/32" Wide Jaw, Stationary Base, Standard Speed, 27-3/8" OAL x 1-3/4" Overall Height
Item #: 09143132
Brand: Heinrich
Model #: 13-WH-ASSEMBLY
Exact Tooling IR#: 04
Features and Benefits
Drill press vises with a horizontal orientation are ground on the base only, for horizontal workholding.
Stationary or fixed vises are used for machining straight surfaces. They can be fastened to the machine at either a parallel or at a right angle.
Standard spindle operations feature a continuous nut design for consistent jaw movement.
| Product Specifications | |
|---|---|
| Jaw Width (Inch) | 5-21/32 |
| Jaw Opening Capacity (Inch) | 12-3/4 |
| Jaw Opening Capacity (Decimal Inch) | 12.7500 |
| Throat Depth (Inch) | 3 |
| Throat Depth (Decimal Inch) | 3.0000 |
| Orientation Type | Horizontal |
| Base Motion Type | Stationary |
| Spindle Operation Type | Standard |
| Overall Length (Inch) | 27-3/8 |
| Overall Height (Inch) | 1-3/4 |
| Model Number | 13-WH |
| Jaw Style | V-Groove |
