De-Sta-Co - 10-32 Carbon Steel Cap Tip Clamp Spindle Assembly - 25.65mm Thread Length, 35.05mm OAL, Flat Tip Cap, 0.56" Tip Surface Diam, Use with Toggle Clamps
Item #: 06993034
Brand: De-Sta-Co
Model #: 201208
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Application | Toggle Clamps |
| Spindle Material | Carbon Steel |
| Thread Size | 10-32 |
| Thread Length (Decimal Inch) | 1.0100 |
| Thread Length (mm) | 25.65 |
| Overall Length (mm) | 35.05 |
| Overall Length (Decimal Inch) | 1.3800 |
| Tip Type | Cap |
| Tip Surface Diameter (mm) | 14.22 |
| Tip Surface Diameter (Decimal Inch) | 0.5600 |
| Tip Cap Material | Neoprene |
| Tip Cap Shape | Flat Tip |
| Tip Maximum Diameter (mm) | 11.18 |
| Tip Maximum Diameter (Decimal Inch) | 0.4400 |
| Tip Cap Hardness (Durometer) | 70-80A |
| Nut Height (Decimal Inch) | 0.1300 |
| Nut Height (mm) | 3.30 |
| Minimum Operating Temperature (F) | -22.00 |
| Maximum Operating Temperature (F) | 212.00 |
| Includes | Jam Nuts |
| For Use With | Manual Operated Clamps |
