Brand: Widia / Part #: 6524558
Item #: 99556516
Brand: Widia
Model #: 6524558
Product Specifications
| Minimum Cutting Diameter (mm) | 315.00 |
| Maximum Cutting Diameter (mm) | 327.74 |
| Maximum Depth of Cut (mm) | 17.30 |
| Arbor Hole Diameter (Decimal Inch) | 2.3622 |
| Lead Angle | 70.000 |
| Compatible Insert Size Code | 201012 |
| Cutter Style | M4070 |
| Cutting Direction | Right Hand |
| Insert Holding Method | Screw |
| Rake | Negative |
| Series | M4070 |
| Hub Diameter (mm) | 225.000 |
| Overall Height (Mm - 5 Decimals) | 63.00000 |
| Maximum Body Diameter (Decimal Inch) | 13.3858 |
| Maximum Body Diameter (mm) | 340.00 |
| Tool Application | Chamfering; Facing |
| Tool Performance | General Purpose |
| Primary Workpiece Material | Universal |
| Complete Insert Compatibility | LNGU |
| Toolholder Material | Steel |
| Manufacturers Catalog Number | M4070D315Z15S60LN20 |
| Number Of Cutter Inserts | 15 |
| Coolant Through | No |
| Number Of Flutes | 15 |
