Collis Tool - 1/2" ID, 1" OD, 2-3/4" Length Under Head, Type C Lathe Tool Holder Bushing - 3/16" Head Thickness, 2-3/8" Slot Length
Item #: 05879366
Brand: Collis Tool
Model #: 85513
Exact Tooling IR#: 04
Features and Benefits
C toolholder bushings are designed with an elongated slot and can be used with most Computer Numerical Control (CNC) lathes. They are considered to be universal and can be used for several set screw configurations.
| Product Specifications | |
|---|---|
| Type | C |
| Outside Diameter (Decimal Inch) | 1.0000 |
| Outside Diameter (Inch) | 1 |
| Inside Diameter (Inch) | 1/2 |
| Inside Diameter (Decimal Inch) | 0.5000 |
| Head Thickness (Inch) | 3/16 |
| Head Thickness (Decimal Inch) | 0.1875 |
| Length Under Head (Inch) | 2-3/4 |
| Length Under Head (Decimal Inch) | 2.7500 |
| Slot Length (Inch) | 2-3/8 |
| Slot Length (Decimal Inch) | 2.3750 |
