Collis Tool - 7/8" ID, 1-3/4" OD, 3" Length Under Head, Type J Lathe Tool Holder Bushing - 7/8" Hole Diam, 3/16" Head Thickness
Item #: 05879176
Brand: Collis Tool
Model #: 85463
Exact Tooling IR#: 04
Features and Benefits
J toolholder bushings are designed with a long solid body and two cearance holes for set screw clamping directly onto the tool.
| Product Specifications | |
|---|---|
| Type | J |
| Outside Diameter (Decimal Inch) | 1.7500 |
| Outside Diameter (Inch) | 1-3/4 |
| Inside Diameter (Inch) | 7/8 |
| Inside Diameter (Decimal Inch) | 0.8750 |
| Head Thickness (Inch) | 3/16 |
| Head Thickness (Decimal Inch) | 0.1875 |
| Length Under Head (Inch) | 3 |
| Length Under Head (Decimal Inch) | 3.0000 |
| Distance Between Hole Centers (Decimal Inch) | 1.2500 |
| Hole Diameter (Decimal Inch) | 0.8750 |
