Vlier - 0.521" Body Len x 1/4" Body Diam, 0.168" Plunger Diam, 2.5 Lb Init to 6 Lb Final End Force, 0.521" Len Under Flange, Stainless Steel Press Fit Spring Plunger - 5/16" Flange Diam, 0.055" Flange Thickness, 0.576" Plunger Len, 1/8" Plunger Projection
Item #: 05137815
Brand: Vlier
Model #: SPFP54
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Body Diameter (Decimal Inch) | 0.2500 |
| Body Length (Decimal Inch) | 0.5210 |
| Length Under Flange (Decimal Inch) | 0.5210 |
| Plunger Diameter (Decimal Inch) | 0.1680 |
| Initial End Force (Lb.) | 2.50 |
| Final End Force (Lb.) | 6.00 |
| Locking Element | No |
| Flange Diameter (Decimal Inch) | 0.3120 |
| Flange Thickness (Decimal Inch) | 0.0550 |
| Plunger Length (Decimal Inch) | 0.5760 |
| Plunger Projection (Decimal Inch) | 0.1250 |
| Body Material | Stainless Steel |
| Nose Material | Stainless Steel |
