Kennametal - KRR658652, KC9115RR Grade Carbide Profiling Insert - Parallelogram, 1.25" Side Length, 1/2" Thick, 3/16" Corner Radius
Item #: 05006846
Brand: Kennametal
Model #: 2487881
Exact Tooling IR#: 04
Features and Benefits
Solid carbide is extremely heat resistant and used for high speed applications on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
| Product Specifications | |
|---|---|
| Material | Carbide |
| Insert Style | KRR |
| Insert Size | 658652 |
| Manufacturer's Grade | KC9115RR |
| Width (mm) | 19.05 |
| Width (Decimal Inch) | 0.7500 |
| Thickness (mm) | 12.70 |
| Thickness (Decimal Inch) | 0.5000 |
| Thickness (Inch) | 1/2 |
| Corner Radius (mm) | 4.76 |
| Corner Radius (Inch) | 3/16 |
| Corner Radius (Decimal Inch) | 0.1875 |
| Length (Decimal Inch) | 1.2500 |
| Length (mm) | 31.75 |
| Hole Diameter (mm) | 7.87 |
| Hole Diameter (Decimal Inch) | 0.3098 |
| Rake | Positive |
| Rake Angle | 10 |
| Side Length (Decimal Inch) | 1.2500 |
| Side Length (mm) | 31.75 |
| Primary Workpiece Material | P |
| Chipbreaker | 52 |
| Shape | Parallelogram |
