Corner Radius End Mill: 1/4″ Dia, 3/4″ LOC, 0.06″ Radius, 2 Flutes, Solid Carbide 2-1/2″ OAL, 1/4″ Shank Dia, 30 ° Helix, Bright/Uncoated, Corner Radius End, Centercutting, Series 2022
Item #: 04078762
Brand: OSG
Model #: 20222000
Product Specifications
| Mill Diameter (Decimal Inch) | 0.2500 |
| Mill Diameter (Inch) | 1/4 |
| Length of Cut (Inch) | 3/4 |
| Corner Radius (Decimal Inch) | 0.0600 |
| Number Of Flutes | 2 |
| End Mill Material | Solid Carbide |
| Extended Reach | No |
| End Type | Corner Radius |
| Length Type | Regular |
| Flute Type | Spiral |
| Helix Angle | 30 |
| Centercutting | Yes |
| Variable Index | No |
| Variable Helix | No |
| Shank Diameter (Inch) | 1/4 |
| Overall Length (Inch) | 2-1/2 |
| Mill Diameter Tolerance | 0.000000 to -0.002000 in |
| Cutting Direction | Right Hand |
| Flute Direction | Right Hand |
| Series | 2022 |
| Single Or Double End | Single |
| Coating/Finish | Bright/Uncoated |
| Length Of Cut (Decimal Inch - 4 Decimals) | 0.7500 |
