Value Collection - 27/32" Diam, 30° Tooth Angle, 42 TPI, Standard (Shape), Cut Type Powdered Metal High Speed Steel Left-Hand Diagonal Knurl Wheel - 0.197" Face Width, Circular Pitch, 30° Helix, Bright Finish
Item #: 03297603
Brand: Value Collection
Exact Tooling IR#: 04
Features and Benefits
Left-hand diagonal wheels are designed to produce right-hand diagonal patterns. On a two-wheel knurling tool, left and right diagonal wheels are used together to create a diamond design.
Cut type wheels produce textured patterns by cutting into and removing material from the workpiece. They reduce the diameter of the workpiece as the pattern is applied.
Powdered metal high speed steel is durable and wear resistant coating used in general purpose applications. It is commonly used on low carbon alloys and mild steels.
| Product Specifications | |
|---|---|
| Knurl Shape | Standard |
| Pattern | Left-Hand Diagonal |
| Form or Cut Type | Cut |
| Material | Powdered Metal High Speed Steel |
| Knurl Diameter (Inch) | 27/32 |
| Face Width (Decimal Inch) | 0.1970 |
| Pitch System | Circular |
| Pitch (mm) | 0.60 |
| Pitch (TPI) | 42 |
| Included Tooth Angle | 30 |
| Finish/Coating | Bright |
| Helix Angle | 30 |
