Made in USA - 21.5mm Diam, 90° Tooth Angle, 25 TPI, Standard (Shape), Cut Type Cobalt Left-Hand Diagonal Knurl Wheel - 5mm Face Width, 8mm Hole, Circular Pitch, 30° Helix, Bright Finish, Series CC
Item #: 02382364
Brand: Made in USA
Exact Tooling IR#: 04
Features and Benefits
Left-hand diagonal wheels are designed to produce right-hand diagonal patterns. On a two-wheel knurling tool, left and right diagonal wheels are used together to create a diamond design.
Cut type wheels produce textured patterns by cutting into and removing material from the workpiece. They reduce the diameter of the workpiece as the pattern is applied.
Cobalt is harder than high speed steel and provides better wear resistance. It is commonly used on high tensile alloys.
| Product Specifications | |
|---|---|
| Knurl Shape | Standard |
| Pattern | Left-Hand Diagonal |
| Form or Cut Type | Cut |
| Material | Cobalt |
| Knurl Diameter (mm) | 21.50 |
| Face Width (mm) | 5.00 |
| Hole Diameter (mm) | 8.00 |
| Pitch System | Circular |
| Pitch (mm) | 1.00 |
| Pitch (TPI) | 25 |
| Knurl Series | CC |
| Included Tooth Angle | 90 |
| Finish/Coating | Bright |
| Helix Angle | 30 |
