De-Sta-Co - M5 Carbon Steel Cap Tip Clamp Spindle Assembly - 24.89mm Thread Length, 28.96mm OAL, Flat Tip Cap, 0.39" Tip Surface Diam, Use with Toggle Clamps
Item #: 02307924
Brand: De-Sta-Co
Model #: 305208-M
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Application | Toggle Clamps |
| Spindle Material | Carbon Steel |
| Thread Size | M5 |
| Thread Length (Decimal Inch) | 0.9800 |
| Thread Length (mm) | 24.89 |
| Overall Length (mm) | 28.96 |
| Overall Length (Decimal Inch) | 1.1400 |
| Tip Type | Cap |
| Tip Surface Diameter (mm) | 9.91 |
| Tip Surface Diameter (Decimal Inch) | 0.3900 |
| Tip Cap Material | Neoprene |
| Tip Cap Shape | Flat Tip |
| Tip Cap Hardness (Durometer) | 80-85A |
| Nut Height (Decimal Inch) | 0.1100 |
| Nut Height (mm) | 2.79 |
| Minimum Operating Temperature (F) | -22.00 |
| Maximum Operating Temperature (F) | 212.00 |
| Includes | Jam Nuts |
| For Use With | 201 Vertical Hold Down Clamp; 305 Horizontal Hold Down Clamp; 812 Pneumatic Clamp |
