VDI Style Taper Drill Sockets - (Inch)
![](http://usatoolandsupply.com/cdn/shop/t/2/assets/vdistyletaperdrillsockets.png?v=26953594811832306511591160855)
VDI Style
Adapt your VDI Boring Bar Holder into a Morse Taper Holder by adding this inexpensive Bushing. Save money by using your existing Boring Bar Holder and purchasing this inexpensive Bushing. To order any of these items enter the Part Number into the search bar above. (This will take you to the product page where you can add the item to the shopping cart)
d1 | MT | d2 | L1 | L2 | L3 | Part Number |
1-1/2" | 1 | 52mm | 60mm | 16mm | 76mm | CNC86 64.4073#1 |
2 | 60mm | 16mm | 76mm | CNC86 64.4073#2 | ||
3 | 71mm | 43mm | 114mm | CNC86 64.4073#3 | ||
4 | 71mm | 43mm | 114mm | CNC86 64.4073#4 | ||
1-3/4" | 1 | 57mm | 60mm | 16mm | 76mm | CNC86 64.4083#1 |
2 | 60mm | 16mm | 76mm | CNC86 64.4083#2 | ||
3 | 81mm | 33mm | 114mm | CNC86 64.4083#3 | ||
4 | 81mm | 33mm | 114mm | CNC86 64.4083#4 | ||
5 | 81mm | 69mm | 150mm | CNC86 64.4083#5 | ||
2" | 1 | 64mm | 60mm | 16mm | 76mm | CNC86 64.4583#1 |
2 | 60mm | 16mm | 76mm | CNC86 64.4583#2 | ||
3 | 81mm | 33mm | 114mm | CNC86 64.4583#3 | ||
4 | 81mm | 33mm | 114mm | CNC86 64.4583#4 | ||
5 | 81mm | 69mm | 150mm | CNC86 64.4583#5 |
